รายละเอียดสินค้า:
การชำระเงิน:
|
| ตัวนำ: | ทองแดงเปลือย | ฉนวน: | EVI-2 |
|---|---|---|---|
| เสื้อแจ็กเกต: | EVM-1 | รูปสายเคเบิล: | กลม |
| แอปพลิเคชัน: | อุตสาหกรรม เครื่องใช้ไฟฟ้า การแพทย์ การชาร์จ EV พลังงานสีเขียว ฯลฯ | การบรรจุหีบห่อ: | บรรจุในม้วน |
| ระเหย: | 1500V DC | อุณหภูมิ: | -40~90℃ |
| PN: | HT2201398 |
| Construction | ||||
| A:3C×16mm2 | B:6C×0.75mm2 | |||
| Conductor | Bare copper stranded | |||
| Cross section | 16mm2 | 0.75mm2 | ||
| Construction | 511/0.20mm | 40/0.15mm+Tinsel+ Kevlar | ||
| Strand Dia.(Ref.) | 5.60mm | 1.30mm | ||
| Insulation | EVI-2 | |||
| Nom.Thickness | 0.80mm | 0.40mm | ||
| Min.Thickness | 0.64mm | 0.32mm | ||
| Insulation Dia. | 7.50±0.35mm | 2.20±0.15mm | ||
| Insulation colour | A1.red,A2.black,A3.green/yellow | B1.orange&blue B2.white &violet B3.brown&gray | ||
| Filler | PP rope | |||
| Tape | Non woven | |||
| Assembly | 3C×16mm2+3P×0.75mm2+W | |||
| Jacket | EVM-1 | |||
| Nom.Thickness | 1.50mm | |||
| Min.Thickness | 1.18mm | |||
| Outer Dia. | 22.20±1.50mm | |||
| Colour | Black | |||
Conductor Bared copper stranded
Cross section 3C×16.0mm2+2C×0.75mm2+W
Construction 511/0.20mm ,,40/0.15mm
Elongation ≥300%
Aged condition 110℃×168H
Insulation EVI-2
Nom.Thickness 0.8 mm
Min.Thickness 0.64 mm
Insulation Dia.7.5±0.35mm
nsulation: :A1.red,A2.black,A3.green/yellow
Jacket EVM-1
Reference standard:IEC standard
Nom.Thickness 1.5 mm
Outer Dia. 22.2±1.5mm
Colour per request
UL758-E258652-20060111A-CertificateofCompliance(2)...
| Electric Performance | ||||||
| Rated Temperature | -40~90℃ | |||||
| Voltage rating | 1.5KV DC | |||||
| Max.conductor DC resistance(20℃) | A:1.21Ω/km | |||||
| B:26Ω/km | ||||||
| Dielectric Strength AC | 3.5kV/5min | |||||
